Jergens Ball Lock® Face Mount Receiver Bushing, Shank Diameter (mm): 25
Jergens Ball Lock® Face Mount Receiver Bushing, Shank Diameter (mm): 25
SKU: 49502
Brand: Jergens
Ball Lock® Face Mount Receiver Bushing
$72.67
Additional Information
- Shank Diameter (mm): 25
- Outside Diameter (inch): 2.0623
- Clearance Drill Diameter E (inch): 1
- Bore F (inch): 2.0623
- Depth G (inch): 0.799
- Tap Size & Depth H: 1/4-28 x 1/2
- Bolt Circle Diameter (inch): 1.644
- Min Subplate Thickness D (inch): 1-1/4
- Material: 4340 Steel
- Finish: Black Oxide
- Heat Treat: 50-54 RC
- Operating Temperature Range: -20°F to 400°F (-30°C to 200°C)
Jergens Ball Lock® Face Mount Receiver Bushings are generally utilized in blind hole applications (Slip Fit). Cap screws supplied. Installed bushings should be approximately 0.012" (0.3mm) below subplate surface.
