Carr Lane, Vertical Toggle Clamp, Clamping Force (lbf): 625, Open Arm, Flanged Base, Steel
Carr Lane, Vertical Toggle Clamp, Clamping Force (lbf): 625, Open Arm, Flanged Base, Steel
SKU: CL-201-TC
Brand: Carr Lane
Vertical Toggle Clamp
$22.89
Additional Information
- Clamping Force (lbf): 625
- Arm Type: Open Arm
- Base Type: Flanged Base
- Style: Steel
- Material: 1008, 1010, and/or 1018 Steel (Clamp Body),
- Finish: Zinc plated clear chromate
- Open-arm models accept any 5/16-18 or M8 spindle and (2) CL-51610-TW flanged washers. Solid-arm models accept any 5/16-18 spindle and CL-51658-S weld-on bolt retainer. Order all accessories separately (see Related Products below).
Simple, easy-opening toggle clamps with extra arm height. Arm opens 83° while handle moves 83° – ideal when wide opening is not desirable. Choose either an open arm for adjustable spindle location, or a solid arm for fixed spindle location. Open-arm clamps are optionally available with a straight base. 625 lbs holding capacity.
