Name: Carr Lane, Horizontal Toggle Clamp, Clamping Force (lbf): 600, Open Arm, Flanged Base,
Brand: Carr Lane
SKU: CL-450-HTC-S
Availability: InStock

Carr Lane, Horizontal Toggle Clamp, Clamping Force (lbf): 600, Open Arm, Flanged Base,

SKU: CL-450-HTC-S

Brand: Carr Lane

View Specs

Horizontal Toggle Clamp

$42.03

Additional Information

Clamping Force (lbf): 600
Arm Type: Open Arm
Base Type: Flanged Base
Style: Stainless Steel

Material: 300-Series Stainless (Clamp Body),
Finish: N/A

Supplied with 5/16-18 short flat-cushion spindle CL-518208-FC and (2) CL-51610-TW flanged washers. For alternative clamping spindles, Contact Us.

Strong-yet-compact horizontal-handle clamp. Arm opens 90° while handle moves 65°. Open arm provides adjustable spindle location. Choice of flanged base or straight base. Available in in steel or stainless steel. Optionally available with our safety-lock feature (see Related Products below). 500 lbs holding capacity.
