Name: Carr Lane, Horizontal Toggle Clamp, Clamping Force (lbf): 500, Open Arm, Flanged Base, Steel, Red Handle
Brand: Carr Lane
SKU: CL-450-HTC-R
Availability: InStock

Carr Lane, Horizontal Toggle Clamp, Clamping Force (lbf): 500, Open Arm, Flanged Base, Steel, Red Handle

SKU: CL-450-HTC-R

Brand: Carr Lane

View Specs

Horizontal Toggle Clamp

$18.77

Additional Information

Clamping Force (lbf): 500
Arm Type: Open Arm
Base Type: Flanged Base
Style: Steel
Handle Color: Red Handle

Material: 1008, 1010, and/or 1018 Steel (Clamp Body),
Finish: Zinc plated clear chromate

Supplied with 5/16-18 short flat-cushion spindle CL-518208-FC and (2) CL-51610-TW flanged washers. For alternative clamping spindles, Contact Us.

Strong-yet-compact horizontal-handle clamp. Arm opens 90° while handle moves 65°. Open arm provides adjustable spindle location. Choice of flanged base or straight base. Available in in steel or stainless steel. Optionally available with our safety-lock feature (see Related Products below). 500 lbs holding capacity.
