TE-CO ReLock 8-Station Vise, Jaw Style: Hard Jaws, Total Length (C) (inch): 13.90
TE-CO ReLock 8-Station Vise, Jaw Style: Hard Jaws, Total Length (C) (inch): 13.90
SKU: RWS40S8HJ
Brand: TE-CO
ReLock 8-Station Vise
$9,537.00
Additional Information
- Type: 8-Station
- Jaw Style: Hard Jaws
- A (inch): 7.00
- B (inch): 4.00
- Total Length (C) (inch): 13.90
- Package Contents: 1-RWS40S8
- 4-SCJ4000
- 4-SHJ4035
- Weight (lb): 138
- Designed for machining center with small work envelopes like the Tsugami FMA3.
- Through column mounting holes are included to mount directly to the pallet of an HMC without the need for a baseplate.
- Clamping pressure = 0 to 6,000 lbs.
- Recommended foot lbs. = 45-50.
- Mounting kit included.
The ReLock Vise System combines high manufactured tolerances with unequalled versatility in providing
two-station and eight-station production vises. ReLock CNC vises, available with machinable soft jaws, hard jaws, master jaws and parallels, or fixture plates, allow the machinist a variety of configurations with the same vise. Bodies are manufactured from 80,000 PSI ductile cast iron, and ways are flame hardened and ground to accuracies of +/- .0005. Manual and hydraulic two-station and eight-station vises are available in widths of 4”, 6” and 8.
