Carr Lane, Vertical Toggle Clamp, Clamping Force (lbf): 500, Open Arm, Flanged Base, Stainless Steel
Carr Lane, Vertical Toggle Clamp, Clamping Force (lbf): 500, Open Arm, Flanged Base, Stainless Steel
SKU: CL-450-VTC-S
Brand: Carr Lane
Vertical Toggle Clamp
$51.45
Additional Information
- Clamping Force (lbf): 500
- Arm Type: Open Arm
- Base Type: Flanged Base
- Style: Stainless Steel
- Material: 300-Series Stainless (Clamp Body),
- Finish: N/A
- Accepts any 5/16-18 or M8 short spindle (see Related Products below). Steel open-arm version supplied with (2) CL-51610-TW flanged washers. Solid-arm version supplied with CL-518000-BR weld-on bolt retainer. Stainless steel open-arm version supplied with (2) CL-51610-TW-S stainless flanged washers.
Popular wide-opening clamp, available in many configurations. Arm opens 100° while handle moves 69°. Choose either an open arm for adjustable spindle location, or a solid arm for fixed spindle location. Extra-long arms are also available. Choice of flanged base or straight base. Available in in steel or stainless steel. Optionally available with our safety-lock feature, and in an air-powered version (see Related Products below). 500 lbs holding capacity.
