Carr Lane, Vertical Toggle Clamp, Clamping Force (lbf): 500, Open Arm, Flanged Base, Stainless Steel
Carr Lane, Vertical Toggle Clamp, Clamping Force (lbf): 500, Open Arm, Flanged Base, Stainless Steel
SKU: CL-450-LVTC-S
Brand: Carr Lane
Vertical Toggle Clamp
$74.07
Additional Information
- Clamping Force (lbf): 500
- Arm Type: Open Arm
- Base Type: Flanged Base
- Style: Stainless Steel
- Material: 300-Series Stainless (Clamp Body),
- Finish: N/A
- Accepts any 5/16-18 or M8 short spindle (see Related Products below). Steel open-arm version supplied with (2) CL-51610-TW flanged washers. Solid-arm version supplied with CL-518000-BR weld-on bolt retainer. Stainless steel open-arm version supplied with (2) CL-51610-TW-S stainless flanged washers.
Safety-lock version of CL-450-VTC toggle clamp. The integral safety lock automatically engages when the clamp is closed, then remains locked until manually disengaged by pressing the lever before opening. This prevents the clamp from being accidentally opened by bumping the handle. Popular size of wide-opening clamp. Arm opens 100° while handle moves 69°. Choose either an open arm for adjustable spindle location, or a solid arm for fixed spindle location. Available in in steel or stainless steel. 500 lbs holding capacity.
