Carr Lane, Horizontal Toggle Clamp, Clamping Force (lbf): 625, Open Arm, Flanged Base, Steel
Carr Lane, Horizontal Toggle Clamp, Clamping Force (lbf): 625, Open Arm, Flanged Base, Steel
SKU: CL-251-TC
Brand: Carr Lane
Horizontal Toggle Clamp
$22.46
Additional Information
- Clamping Force (lbf): 625
- Arm Type: Open Arm
- Base Type: Flanged Base
- Style: Steel
- Material: 1008, 1010, and/or 1018 Steel (Clamp Body),
- Finish: Zinc plated clear chromate
- Accepts any 1/4-20 or M6 spindle and (2) CL-148-TW flanged washers. For fixed spindle location, use weld-on bolt retainer CL-1458-S instead of the flanged washers. To order accessories, Contact Us.
Classic-design horizontal-handle clamp with a low clamping arm. Arm opens 90° while handle moves 90°. Open arm provides adjustable spindle location. Choice of flanged base or straight base. 625 lbs holding capacity.
