Carr Lane, Horizontal Toggle Clamp, Clamping Force (lbf): 150, Open Arm, Flanged Base, Steel
Carr Lane, Horizontal Toggle Clamp, Clamping Force (lbf): 150, Open Arm, Flanged Base, Steel
SKU: CL-260-HTC
Brand: Carr Lane
Horizontal Toggle Clamp
$14.03
Additional Information
- Clamping Force (lbf): 150
- Arm Type: Open Arm
- Base Type: Flanged Base
- Style: Steel
- Material: 1008, 1010, and/or 1018 Steel (Clamp Body),
- Finish: Zinc plated clear chromate
- Steel clamps are supplied with #10-32 flat-cushion spindle CL-316112-FC and (2) CL-3166-TW flanged washers. Stainless steel clamps are supplied with #10-32 stainless hex-head spindle CL-316100-SA-S and (2) CL-3166-TW-S stainless flanged washers. For alternative clamping spindles, Contact Us.
An extremely powerful clamp for its small size. Arm opens 90° while handle moves 75°. Open arm provides adjustable spindle location. Available in steel and stainless steel. 150 lbs holding capacity.
