Name: Carr Lane, Vertical Toggle Clamp, Clamping Force (lbf): 125, Open Arm, Flanged Base, Stainless Steel
Brand: Carr Lane
SKU: CL-150-VTC-S
Availability: InStock

Carr Lane, Vertical Toggle Clamp, Clamping Force (lbf): 125, Open Arm, Flanged Base, Stainless Steel

SKU: CL-150-VTC-S

Brand: Carr Lane

View Specs

Vertical Toggle Clamp

$32.69

Additional Information

Clamping Force (lbf): 125
Arm Type: Open Arm
Base Type: Flanged Base
Style: Stainless Steel
Handle Style: T Handle

Material: 300-Series Stainless (Clamp Body),
Finish: N/A

Steel clamps are supplied with #10-32 flat-cushion spindle CL-316112-FC and (2) CL-3166-TW flanged washers. Stainless steel clamps are supplied with stainless hex-head spindle CL-316100-SA-S and (2) CL-3166-TW-S stainless flanged washers. For alternative clamping spindles, or to order an optional bracket for 90? mounting, Contact Us.

Smallest wide-opening hold-down toggle clamp available. Arm opens 100? while handle moves 56?. Open arm provides adjustable spindle location. Choice of flanged base or straight base. Available in steel or stainless steel. Also available in an air-powered version (see Related Products below). 100 lbs holding capacity.
