Carr Lane, Horizontal Toggle Clamp, Clamping Force (lbf): 750, Open Arm, Flanged Base, Steel
Carr Lane, Horizontal Toggle Clamp, Clamping Force (lbf): 750, Open Arm, Flanged Base, Steel
SKU: CL-550-LHTC
Brand: Carr Lane
Horizontal Toggle Clamp
$72.79
Additional Information
- Clamping Force (lbf): 750
- Arm Type: Open Arm
- Base Type: Flanged Base
- Style: Steel
- Material: 1008, 1010, and/or 1018 Steel (Clamp Body),
- Finish: Zinc plated clear chromate
- Supplied with 3/8-16 short flat-cushion spindle CL-38212-FC and (2) CL-3811-TW flanged washers. For alternative clamping spindles, Contact Us.
Safety-lock version of CL-550-HTC toggle clamp. The integral safety lock automatically engages when the clamp is closed, then remains locked until manually disengaged by pressing the lever before opening. This prevents the clamp from being accidentally opened by bumping the handle. Heavy-duty horizontal-handle clamp. Arm opens 90° while handle moves 55°. Open arm provides adjustable spindle location. 750 lbs holding capacity.
