Carr Lane, Horizontal Toggle Clamp, Clamping Force (lbf): 75, Open Arm, Straight Base, Stainless Steel
Carr Lane, Horizontal Toggle Clamp, Clamping Force (lbf): 75, Open Arm, Straight Base, Stainless Steel
SKU: CL-250-HTC-S
Brand: Carr Lane
Horizontal Toggle Clamp
$21.43
Additional Information
- Clamping Force (lbf): 75
- Arm Type: Open Arm
- Base Type: Straight Base
- Style: Stainless Steel
- Material: 300-Series Stainless (Clamp Body)
- Finish: N/A
- Steel clamps are supplied with #8-32 nylon hex-head spindle CL-832203-SA. Open-arm steel versions are additionally supplied with (2) CL-832-TW flanged washers. Stainless steel clamps are supplied with #8-32 stainless hex-head spindle CL-83234-SA-S. Open-arm stainless steel versions are additionally supplied with (2) CL-832-TW-S stainless flanged washers. For alternative clamping spindles, Contact Us.
Small hold-down toggle clamp. Arm opens 90° while handle moves 80°. Choose either an open arm for adjustable spindle location, or a solid arm for fixed spindle location. Choice of flanged base or straight base (several options). Available in steel or stainless steel. 60 lbs holding capacity.
