Name: Carr Lane, Horizontal Toggle Clamp, Clamping Force (lbf): 375, Open Arm, Flanged Base, Steel
Brand: Carr Lane
SKU: CL-475-HTC
Availability: InStock

Carr Lane, Horizontal Toggle Clamp, Clamping Force (lbf): 375, Open Arm, Flanged Base, Steel

SKU: CL-475-HTC

Brand: Carr Lane

View Specs

Horizontal Toggle Clamp

$31.35

Additional Information

Clamping Force (lbf): 375
Arm Type: Open Arm
Base Type: Flanged Base
Style: Steel

Material: 1008, 1010, and/or 1018 Steel (Clamp Body),
Finish: Zinc plated clear chromate

Accepts any 5/16-18 or M8 spindle (see Related Products below). Solid-arm version supplied with CL-518000-BR weld-on bolt retainer. Open-arm version supplied with (2) CL-51610-TW flanged washers.

Extra-wide-opening clamp with a handle that locks at a downward angle. Unique up-then-down handle motion opens the clamping arm a full 185°. Dual flange bases allow mounting on vertical surfaces as well as horizontal. Choose either an open arm for adjustable spindle location, or a solid arm for fixed spindle location. 375 lbs holding capacity.
