Carr Lane, Horizontal Toggle Clamp, Clamping Force (lbf): 1000, Open Arm, Flanged Base, Steel
Carr Lane, Horizontal Toggle Clamp, Clamping Force (lbf): 1000, Open Arm, Flanged Base, Steel
SKU: CL-650-HTC
Brand: Carr Lane
Horizontal Toggle Clamp
$63.96
Additional Information
- Clamping Force (lbf): 1000
- Arm Type: Open Arm
- Base Type: Flanged Base
- Style: Steel
- Material: 1008, 1010, and/or 1018 Steel (Clamp Body),
- Finish: Zinc plated clear chromate
- Supplied with 1/2-13 hex-head spindle CL-12314-SA. The open-arm version is additonally supplied with (2) CL-1213-TW flanged washers. The solid-arm version is additionally supplied with CL-113000-BR weld-on bolt retainer. For alternative clamping spindles, Contact Us.
Large and strong horizontal-handle hold-down clamp. Arm opens 105° while handle moves 75°. Choose either an open arm for adjustable spindle location, or a solid arm for fixed spindle location. 1000 lbs holding capacity.
