Good Hand · Pneumatic Push Pull Toggle Clamps
Pneumatic Push Pull Toggle Clamps GH-36301-A
- MPN
- GH-36301-A
- SKU
- TC-GDHD-000293
Pneumatic Push Pull Toggle Clamps GH-36301-A — ◆Holding Capacity: 45kg; ◆Plunger Stroke( mm): 6.8mm; ◆Weight: 0.26kg
Request pricing
Good Hand prices this line on request. Add it to your quote — we answer within 1 business day, and quotes carry the exact part number so nothing gets re-found.
01About this part
The Good Hand GH-36301-A is a toggle clamp from the Pneumatic Push Pull Toggle Clamps line. It is specified at 99.2 lb holding force and 0.6 lb shipping weight. It locks workpieces quickly and repeatably for machining, welding, assembly and inspection fixtures, releasing in one motion to keep cycle times short. All Industry Supplies sources this item for Minnesota-area manufacturers, with certification documentation available on request for aerospace, medical and defense work.
02Specifications
| Holding force | 99.2 |
|---|---|
| Weight | 0.6 |
| ◆Weight | 0.26kg |
| ◆Cylinder Bore | 20mm |
| ◆Holding Capacity | 45kg |
| ◆Spindle Supplied | SA-042007(NYLON) |
| ◆Air Connection Size | 1/8PT |
| ◆Plunger Stroke( mm) | 6.8mm |
| ◆Max Cylinder Air Pressure | 10kgf/cm2 |
03Common questions
How do I get a price for the Good Hand GH-36301-A?
Add it to a quote request or call 1-763-421-8250. All Industry Supplies answers quote requests within 1 business day.
What is the holding force of the Good Hand GH-36301-A?
99.2. Full specifications are on this page and in the manufacturer's spec sheet.
Is the Good Hand GH-36301-A available from stock?
All Industry Supplies sources Good Hand to order from the manufacturer. Lead times are confirmed on your quote — most items ship within days.
