Pneumatic Vertical Toggle Clamps GH-12132-A
- MPN
- GH-12132-A
- SKU
- TC-GDHD-000139
Pneumatic Vertical Toggle Clamps GH-12132-A — ◆Holding Capacity: 227kgf; ◆Bar Openes: 55°; ◆Weight: 0.88kg
Request pricing
Good Hand prices this line on request. Add it to your quote — we answer within 1 business day, and quotes carry the exact part number so nothing gets re-found.
01
About the Good Hand GH-12132-A
The Good Hand GH-12132-A is a toggle clamp from the Pneumatic Vertical Toggle Clamps line. It is specified at 500.4 lb holding force and 1.9 lb shipping weight. It locks workpieces quickly and repeatably for machining, welding, assembly and inspection fixtures, releasing in one motion to keep cycle times short. All Industry Supplies sources this item for Minnesota-area manufacturers, with certification documentation available on request for aerospace, medical and defense work.
02
Specifications
| Holding force | 500.4 |
|---|---|
| Weight | 1.9 |
| ◆Weight | 0.88kg |
| ◆Bar Openes | 55° |
| ◆Cylinder Bore | 30mm |
| ◆Flanged Washers | FW-516 |
| ◆Holding Capacity | 227kgf |
| ◆Spindle Supplied | FC-086312 |
| ◆Air Connection Size | 1/8PT |
| ◆Max Cylinder Air Pressure | 10kgf/cm2 |
03
Common questions about the Good Hand GH-12132-A
How do I get a price for the Good Hand GH-12132-A?
Add it to a quote request or call 1-763-421-8250. All Industry Supplies answers quote requests within 1 business day.
What is the holding force of the Good Hand GH-12132-A?
500.4. Full specifications for the Good Hand GH-12132-A are listed with the part.
Is the Good Hand GH-12132-A available from stock?
All Industry Supplies sources Good Hand to order from the manufacturer. Lead times are confirmed on your quote — most items ship within days.
