Stainless Steel Ball Plungers 11002

Jergens Ball Plungers are made under extremely accurate machine controls and rigid inspection procedures. Accurate spring alignment is maintained by using a stainless rivet with a long shank on larger sizes of our Ball Plungers. This precisely positions the spring for more accurate ball travel and provides positive control of spring pressure. By minimizing the lining pin head thickness, we are able to use the longest possible springs. Features & Benefits: - Positive control of spring pressure - Less fatigue and longer spring life by minimizing lining pin head thickness - Uniform ball projection keeps variances within ±0.005". - Conforms to TCMA dimensional standards - Patch-style locking element - Special materials and sizes available upon requests Material Specifications: - Body Material: 303 Stainless Steel - Ball Material: 440 Stainless Steel - Spring Material: 17-7 PH Stainless Steel - Thread: Inch: 2A-UNC Metric: Class 6g - Inch: 2A-UNC - Metric: Class 6g Note(s): For easy insertion of Ball Plungers with Locking Elements, the tapped hole should be countersunk at least 0.030"-0.045" (0.76mm-1.14mm) larger than the major diameter of the plunger.
