Base Design Swivots® Gripper Assembly - Replaceable Pad Style - Inch (BBU) BBU-600

Base Design Swivots® Gripper Assembly - Replaceable Pad Style - Inch (BBU). Base Design Swivot - 13/16 in Dia X 7/8 in - Replaceable Ball. The replaceable pad swivels to allow for self-alignment on uneven surfaces. Cylindrical body allows for installation in tight areas. The housing is tapped for backside fastening. The replaceable pad fits in a hardened (Rc 58/60) 440c stainless ball cup and is held in place with a lock screw. The pad can be replaced when worn or a different style pad is required. The housing is made from alloy steel, heat treated to Rc 43/46 with black oxide finish. The parts below are for the Swivot assembly only and do not include a pad. Pads must be ordered separately by selecting any fixed gripper or rest pad with the proper diameter . More Information Specifications: Diameter Overall in: 13/16; Length Body in: 7/8; Length Thread in: 11/32; Thread Internal - Tap: 5/16-24; Degree Swivel Degrees: 24; Standoff in: 1/4; Diameter Ball in: 5/8; Diameter Contact Surface in: 1/2; Rating Load lbs: 10,925.
