Base Design Swivots® Gripper Assembly - Flat Tool Steel Ball - Metric (MBBU-F) MBBU-1722-F-T

Base Design Swivots® Gripper Assembly - Flat Tool Steel Ball - Metric (MBBU-F). Base Design Swivot - 17 mm Dia X 18 mm - Flat - Tall. Cylindrical body allows for installation in tight areas. The housing is tapped for backside fastening. The replaceable flat ball swivels to allow for self-alignment on uneven surfaces. A Viton O-ring holds the ball in place while keeping contaminants out and providing smooth ball movement. The housing is made from alloy steel, heat treated to Rc 43/46 with black oxide finish. The replaceable ball is made from M-2 high speed steel heat treated to Rc 60/62. Replacement balls and O-rings can be ordered separately. Specifications: Diameter Overall mm: 17; Length Body mm: 18; Diameter Contact Surface mm: 10; Height Standoff mm: 6; Degree Swivel Degrees: 42; Thread Internal - Tap: M6x1.0; Length Thread mm: 7.5; Diameter Base mm: 13; Part No. Ball Only mm: MBUB-130-F-T; Rating Load lbs: 6,170.
